Powered Accumulating Conveyor Line

Powered Accumulating Conveyor Line

The Maidi Powered Accumulating Conveyor Line is a state-of-the-art material handling solution engineered specifically for the garment and textile industry. Operating at speeds between 12–30 m/min with precision DC motor control, this system provides automated sorting by style, color, and size, along with temporary buffer storage to balance production line output.

System Architecture

Built on Maidi’s proven IoT platform, the conveyor integrates seamlessly with existing production management systems. Each conveyor zone operates independently with its own DC motor drive, allowing sections to accumulate, release, and redirect garments without manual intervention. The system supports cross-floor integration via inclined sections and vertical lifts.

Technical Specifications

• Conveyor Speed: 12–30 m/min, electronically variable
• Belt Width: 500–800mm (customizable)
• Zone Length: 1200–3000mm per accumulation zone
• Drive System: DC geared motor with variable frequency drive per zone
• Frame Material: Powder-coated steel, stainless steel options available
• Load Capacity: Up to 30 kg/m of conveyor length
• Control System: PLC-based with HMI touchscreen interface
• Communication: RS485/Ethernet, IoT cloud connectivity

Sorting & Accumulation

The system supports multi-criteria automatic sorting — by garment style, color, size, or production order. Barcode and RFID scanning stations at key points enable real-time tracking and routing. Accumulation zones allow temporary buffering, preventing bottlenecks between cutting, sewing, and finishing departments.

Integration & Software

Fully compatible with Maidi’s Fengxing Intelligent Manufacturing Cloud Platform, enabling real-time production monitoring, automated dispatching, and data-driven optimization. The system supports WMS integration for end-to-end garment logistics management.
